Trituradora móvil nuevo FABO MVSI 900 MOBILE VERTICAL SHAFT IMPACT CRUSHING SCREENING PLANT

• All of our products are made with care and covered for 1 year warranty!
• Installation and Operator Training FREE

FABO MVSI Series are mobile type & closed circuit crushing and screening plant known as also SAND MAKING MACHINE that is used for high percentage of cubical shape sand production purpose by processing hard materials such as basalt, granite etc.

MVSI Series includes one stage of crushing process that is made by a Vertical Shaft Impact Crusher which is capable to produce high percentage of sand with good cubical shape.

TECHNICAL SPECIFICATIONS:

Bunker: 25m3

Plant Dimensions: 17000x4000x4550 mm

Production Capacity: 200-300 Tons Per Hour

Crusher Type & Rotor Size: Vertical Shaft Impact Crusher – Ø 900 mm

Maximum Feeding Size: 45 mm

Vibrating Screen Size and Deck: 1700x4500 mm 1 deck

Total Motor Power: 480 Kw

Generator (optional): 600 kvA

MVSI-900 İS A COMBİNATİON OF:

• Hopper

• Vibrating Feeder

• VSI Crusher

• High Stroke Type Vibrating Screen

• Folding type feeding, feedback, bypass and stock conveyor belts

• Hydraulic feet

• Mobile Chassis with axles and tires

• Fully Automation System

• Dust Suppression System

• Easy walking platforms for maintanance

• Diesel Generator (Optional)

FOR FURTHER INFORMATION PLEASE FEEL FREE TO CALL US!!!
